BENEFITS
- Minimizes container/waste disposal
- Reduces environmental risks
- Use in new mine development projects
- Improve availability in remote areas
- Sizes range from 200 to 1000 imperial gallons, with other sizes available on request
- fabricated steel construction withstands rough handling
- Equipped with a thermally activated fire suppression system, automatic closing roll-up door and containment area
- Efficient and cost effective
TECHNICAL SPECIFICATIONS
Features
- Dry disconnect fittings
- Failsafe valve
- Pump and hose reel protective enclosure
- Spill pump out
- Removable grating over containment area
- Lifting points
Fuel Capacity
- Bladder sizes range from 200 to 1000 imperial gallons
- Other sizes available on request
Spill Containment
- Should spillage occur, SatStats spill containment area reduces environmental and safety concerns
- Containment capacity as required by local legislation
Construction
- SatStat fuel station, bladder and containment area are fabricated steel construction to withstand rough handling
- Optional liquid level sight glasses are recessed
Dimensions
- Customized length, width and hose reels are available
- Pump and hose reels are mounted inside a protective enclosure
- Optional dual fuel dispensing systems and hose reels
- Reel mounts as a separate unit for easy handling and installation
Fire Suppression and Overhead Door
- SatStat is equipped with a thermally activated fire suppression system and automatic closing roll-up door which isolates the fuel bladder from the surrounding area in the event of an outstanding fire
- Mine water of chemical fire suppression systems are available
Custom Built
- SatStat Fuel Station can be custom built in various sizes and configurations to meet specific application or cage size restrictions
|
